Trilliant Cut Diamond: more fire than a modern round, on three straight sides

Brilliance 78 · Fire 83 · Scintillation 79 · in our census, where the T73 scores 93 · 78 · 80 in diamond

A three-sided brilliant with straight sides. It has more fire than the T73 and trails it on five scores by our margins. The largest gap is an uneven pavilion.

The Trilliant Cut in diamond, rendered at an angle in our 3D Gemstone Simulator under studio light
Rendered in our 3D Gemstone Simulator from the Trilliant Cut model, 1.00 ct, studio light.

Trilliant Cut Diamond

Straight sides and three sharp corners make the trilliant. Jewelers often set it in pairs on each side of a center stone. Our model has 70 facets and is cut 58.9% deep, with a 39.0° pavilion.

Against the T73 Round Brilliant in diamond it wins on fire and loses on four scores, plus a narrow fifth: Tilt 89 against 92. Scintillation, 79 against 80, is inside our margin. But among the three-sided cuts we measure, it returns the most light. It returns more than the trillion (67) or the triangle (53).

Is a trilliant a good cut for diamond? Pros and cons

Compared with the T73 Round Brilliant in diamond. A difference counts from 3 points (Brilliance, Fire, Tilt, Leakage), 5 (Scintillation, Symmetry), 4% (face-up size per carat) or 5% (weight); Tilt counts as a pro only for a stone within 5 points of the brilliance it is compared with. How we measure.

All eight scores against the T73

At a glance: the Trilliant Cut in diamond (white) against the T73 Round Brilliant in diamond (dashed): solid white where it reaches further, hatched where it falls short. Each pro and con is explained, with pictures, below.

Performance wheel: Trilliant Cut in diamond, against the T73 Round Brilliant in diamond as an outline. Solid white marks where it reaches further, hatching where it falls short. The scores are listed below.50100Global−10Brilliance−15Fire+5Scintillation−1Spread+1Symmetry−38Shape-norm−9Tilt−3

Against the T73 Round Brilliant in diamond: ahead on 2, behind on 6.

  • Global80, the comparison 90, difference −10
  • Brilliance78, the comparison 93, difference −15
  • Fire83, the comparison 78, difference +5
  • Scintillation79, the comparison 80, difference −1
  • Spread101, the comparison 100, difference +1
  • Symmetry62, the comparison 100, difference −38
  • Shape-norm91, the comparison 100, difference −9
  • Tilt89, the comparison 92, difference −3
Face-up light census, a different measure from the Cut Grading Tool; Spread and Shape-norm above 100 sit on the ring. Spread is the census's estimate from depth alone; the face-up size in the pros and cons is measured from each model's outline.

What diamond gains in a trilliant

More fire than the T73

Fire 83 against 78 for the T73 Round Brilliant in diamond: 5 points higher

Fire beats the benchmark by a clear margin. The trilliant's long, angled facets send the returning light out in broad flashes, and more of it splits into color.

Trilliant cut in diamond face-up under a single bright light: a render from our simulator, its colored flashes are the fire (score 83)

Trilliant Cut in diamond · Fire 83

T73 round brilliant in diamond face-up under a single bright light: a render from our simulator, its colored flashes are the fire (score 78)

T73 Round Brilliant in diamond · Fire 78

Look at the colored flashes: those are fire. Same light, same size, same face-up angle; rendered by our 3D Gemstone Simulator from each cut's own model.

Try it yourself: See the fire in the 3D Gemstone Simulator

Where the trilliant falls short in diamond

An uneven pavilion

Symmetry 62 against 100 for the T73 Round Brilliant in diamond: 38 points lower

Our symmetry score measures how evenly the pavilion facets repeat within the design, and the trilliant's facets do not. The trillion, also three-sided, scores 100. That points to the facet plan, not the outline.

Trilliant Cut · 70 facets · Symmetry 62

T73 Round Brilliant · 73 facets · Symmetry 100

Symmetry scores how regular the pavilion facets are within the design. Compare how evenly the facets repeat around each pavilion. Drawn from each cut's own model.

What helps: This is the design. The Trillion Cut Diamond keeps three sides with a pavilion that repeats evenly, Symmetry 100, but it returns less light.

Try it yourself: Compare the Symmetry spoke in the Cut Performance Wheel

Much less light than a round

Brilliance 78 against 93 for the T73 Round Brilliant in diamond: 15 points lower

Corners and straight sides give light more places to escape. The census returns 78 where the T73 returns 93.

Trilliant cut in diamond face-up Light Return map: red, green and blue show where the light returns from, gray shows where it leaks (Brilliance 78)

Trilliant Cut in diamond · Brilliance 78

T73 round brilliant in diamond face-up Light Return map: red, green and blue show where the light returns from, gray shows where it leaks (Brilliance 93)

T73 Round Brilliant in diamond · Brilliance 93

Red, green and blue = light returning to the eye; gray = leakage, light that leaves heading down or stays inside. This is the head-on view; the Brilliance score averages a wider cone of light, so the score can differ from what one picture shows.

What helps: No three-sided cut we measure does better. For more light in a side stone, the Square Cut Diamond returns 85 and DG-Octagonal Kite Diamond 88.

Try it yourself: Open this Light Return map in the simulator

More light lost through the back

Leakage 11 against 2 for the T73 Round Brilliant in diamond: 9 points higher

Light lost through the back comes to 11% for the trilliant in our census and 2% for the T73. The pavilion clears our guide minimum, so the loss is not a shallow-angle window.

Trilliant Cut in diamond · Leakage 11

Trilliant cut in diamond tilted 0 degrees: Light Return map, 12% of the face leaking0° · 12% leak
Trilliant cut in diamond tilted 10 degrees: Light Return map, 16% of the face leaking10° · 16% leak
Trilliant cut in diamond tilted 20 degrees: Light Return map, 20% of the face leaking20° · 20% leak
Trilliant cut in diamond tilted 30 degrees: Light Return map, 24% of the face leaking30° · 24% leak

T73 Round Brilliant in diamond · Leakage 2

T73 round brilliant in diamond tilted 0 degrees: Light Return map, 4% of the face leaking0° · 4% leak
T73 round brilliant in diamond tilted 10 degrees: Light Return map, 2% of the face leaking10° · 2% leak
T73 round brilliant in diamond tilted 20 degrees: Light Return map, 9% of the face leaking20° · 9% leak
T73 round brilliant in diamond tilted 30 degrees: Light Return map, 14% of the face leaking30° · 14% leak
Each frame is the Light Return map with the stone tilted away from you by the angle shown; gray is leakage. The share under each frame is that picture's own.

What helps: Steepening is not the fix: the 39.0° pavilion is already above diamond's 38.9° guide minimum. DG-Octagonal Kite Diamond leaks 7%.

Try it yourself: Tilt it yourself in the simulator's light map

Less face for its weight than a round

Face-up size 93 against 100 for the T73 Round Brilliant in diamond (T73 = 100): 7% less face-up area for the same weight

Weigh out a carat of each, and the trilliant's outline covers less area than the T73's circle. This is true although its model is the shallower stone, 58.9% deep against 61.7%. A triangle encloses less area than a circle of the same width. Here that counts for more than the saving in depth. The picture draws both stones at 1.00 ct, to one scale.

Trilliant Cut · 6.59 mm at 1.00 ct · Face-up size 93

T73 Round Brilliant · 6.48 mm at 1.00 ct · Face-up size 100

Both stones weigh 1.00 ct in diamond and are drawn to the same scale in millimeters, from each cut's own model. Face-up size is the outline's area per carat, with the T73 at 100: a deeper stone, or a rounder outline, spreads less area for its weight.

What helps: Compare stones by millimeters, not carats. A 6.5 mm trilliant comes to 0.96 ct. Of the three-sided cuts, the Trillion Cut Diamond faces up larger per carat, at 100.

Try it yourself: See its size at 1.00 ct in diamond in the 3D Gemstone Simulator

Who a trilliant diamond suits

Choose the trilliant for side stones and graphic designs where a triangle is the point and color is welcome. It has more fire than the T73 and the most light of our three-sided cuts.

A setting should protect its sharp corners. If you want a three-sided stone with bowed sides and more face for its weight, choose the Trillion Cut Diamond, but it returns less light. If light matters more than shape, choose a round such as the T73 Round Brilliant Diamond.

Trilliant Cut Diamond: questions

Does a trilliant cut diamond have good fire?

Yes: Fire 83 against 78 for the T73 Round Brilliant in our census.

Trilliant or trillion cut diamond?

In our census the trilliant returns more light, 78 against 67. The trillion has more fire (87) and a larger face for its weight (100 against 93).

Why does a trilliant score low on symmetry?

Its pavilion facets do not repeat evenly within the design: Symmetry 62 against 100 for the T73.

What does a 6.5 mm trilliant diamond weigh?

Our trilliant model comes to 0.96 ct at that width.

Get the Trilliant Cut files

6 formatsMillimetersWatertight

Trilliant Cut 3D files

The Trilliant Cut as exact geometry: 72 planar facets, real-world scale, ready for CAD, rendering, printing and casting.

  • STEPExact faceted solid for CAD
  • 3DMRhino, closed mesh on its own layer
  • STLWatertight mesh for printing and casting
  • OBJMesh for modeling and rendering
  • FBXBlender, 3ds Max, Maya, Cinema 4D, Unity, Unreal
  • GLBWeb, AR and quick previews
GemCad96 index

Trilliant Cut cutting files

The Trilliant Cut as a faceting design: 58 + 12 girdles = 70 facets, 96 index, 3-fold mirror-image symmetry, ready for the machine.

  • .ascGemCad design file, 96 index gear
  • .csvTier table: angles, indices and cutting order
  • DiagramPrintable faceting diagram

Not sure the files open in your software? Get the cube free: the same six formats, for your email address, used only to send them (privacy).

Questions before you buy? Email us.
