Square Cut Diamond: the most light of the square cuts we measure in this stone, still short of a round

Brilliance 85 · Fire 72 · Scintillation 78 · in our census, where the T73 scores 93 · 78 · 80 in diamond

The square counterpart of the round brilliant. It returns more light than any other square cut we measure in diamond, but it still trails the T73 on four scores.

The Square Cut in diamond, rendered at an angle in our 3D Gemstone Simulator under studio light
Rendered in our 3D Gemstone Simulator from the Square Cut model, 1.00 ct, studio light.

Square Cut Diamond

Think of the square brilliant as the round's facet set redrawn on four straight sides, for center and accent stones alike. In the census it is a 69-facet model, 65.0% deep, with a steep 41.39° pavilion.

We compare it with the T73 Round Brilliant. It wins nothing by our margins and loses on brilliance, leakage, fire and tilt. But among our square cuts it leads. The Cushion Cut Diamond returns 80, the Asscher Cut Diamond 69 and the princess 57.

Is a square cut diamond a good choice? Pros and cons

Pros

None by our margins; symmetry, scintillation and face-up size are level with the T73.

Compared with the T73 Round Brilliant in diamond. A difference counts from 3 points (Brilliance, Fire, Tilt, Leakage), 5 (Scintillation, Symmetry), 4% (face-up size per carat) or 5% (weight); Tilt counts as a pro only for a stone within 5 points of the brilliance it is compared with. How we measure.

All eight scores against the T73

At a glance: the Square Cut in diamond (white) against the T73 Round Brilliant in diamond (dashed): solid white where it reaches further, hatched where it falls short. Each pro and con is explained, with pictures, below.

Performance wheel: Square Cut in diamond, against the T73 Round Brilliant in diamond as an outline. Solid white marks where it reaches further, hatching where it falls short. The scores are listed below.50100Global−6Brilliance−8Fire−6Scintillation−2Spread−2Symmetry0Shape-norm+12Tilt−6

Against the T73 Round Brilliant in diamond: ahead on 1, level on 1, behind on 6.

  • Global84, the comparison 90, difference −6
  • Brilliance85, the comparison 93, difference −8
  • Fire72, the comparison 78, difference −6
  • Scintillation78, the comparison 80, difference −2
  • Spread98, the comparison 100, difference −2
  • Symmetry100, the comparison 100, difference 0
  • Shape-norm112, the comparison 100, difference +12
  • Tilt86, the comparison 92, difference −6
Face-up light census, a different measure from the Cut Grading Tool; Spread and Shape-norm above 100 sit on the ring. Spread is the census's estimate from depth alone; the face-up size in the pros and cons is measured from each model's outline.

What diamond gains in a square cut

No score beats the T73 by our thresholds. Symmetry is level at 100, and scintillation is close, 78 against 80. Face-up size per carat matches the round's, 100 to 100. What the square offers is its outline, with more light than any other square cut we measure in diamond.

Where the square cut trails the round

Less light than a round

Brilliance 85 against 93 for the T73 Round Brilliant in diamond: 8 points lower

Corners change the paths that light takes inside the stone, and some of the light never comes back up. In our census that gives 85 against 93.

Square cut in diamond face-up Light Return map: red, green and blue show where the light returns from, gray shows where it leaks (Brilliance 85)

Square Cut in diamond · Brilliance 85

T73 round brilliant in diamond face-up Light Return map: red, green and blue show where the light returns from, gray shows where it leaks (Brilliance 93)

T73 Round Brilliant in diamond · Brilliance 93

Red, green and blue = light returning to the eye; gray = leakage, light that leaves heading down or stays inside. This is the head-on view; the Brilliance score averages a wider cone of light, so the score can differ from what one picture shows.

What helps: In a compact eight-sided outline, DG-Octagonal Kite Diamond returns 88. For the most light we measure in diamond, choose a round: DG-M5 Diamond at 97.

Try it yourself: Open this Light Return map in the simulator

More light leaks through the back

Leakage 10 against 2 for the T73 Round Brilliant in diamond: 8 points higher

A tenth of the light, 10%, escapes through the pavilion. The T73 loses 2%. Our square cuts in diamond are the square, cushion, princess, radiant square, Asscher and emerald square. Of these, only the cushion lets less out, 9%.

Square Cut in diamond · Leakage 10

Square cut in diamond tilted 0 degrees: Light Return map, 7% of the face leaking0° · 7% leak
Square cut in diamond tilted 10 degrees: Light Return map, 11% of the face leaking10° · 11% leak
Square cut in diamond tilted 20 degrees: Light Return map, 16% of the face leaking20° · 16% leak
Square cut in diamond tilted 30 degrees: Light Return map, 22% of the face leaking30° · 22% leak

T73 Round Brilliant in diamond · Leakage 2

T73 round brilliant in diamond tilted 0 degrees: Light Return map, 4% of the face leaking0° · 4% leak
T73 round brilliant in diamond tilted 10 degrees: Light Return map, 2% of the face leaking10° · 2% leak
T73 round brilliant in diamond tilted 20 degrees: Light Return map, 9% of the face leaking20° · 9% leak
T73 round brilliant in diamond tilted 30 degrees: Light Return map, 14% of the face leaking30° · 14% leak
Each frame is the Light Return map with the stone tilted away from you by the angle shown; gray is leakage. The share under each frame is that picture's own.

What helps: Steepening is not the fix our data points to. At 41.39° the pavilion is already above diamond's 38.9° guide minimum. Size does not change that share. DG-Octagonal Kite Diamond loses 7%.

Try it yourself: Tilt it yourself in the simulator's light map

Less fire than the T73

Fire 72 against 78 for the T73 Round Brilliant in diamond: 6 points lower

Fire 72 against 78: what returns carries less color than a round's light does.

Square cut in diamond face-up under a single bright light: a render from our simulator, its colored flashes are the fire (score 72)

Square Cut in diamond · Fire 72

T73 round brilliant in diamond face-up under a single bright light: a render from our simulator, its colored flashes are the fire (score 78)

T73 Round Brilliant in diamond · Fire 78

Look at the colored flashes: those are fire. Same light, same size, same face-up angle; rendered by our 3D Gemstone Simulator from each cut's own model.

What helps: DG-Octagonal Kite Diamond reaches 82 in a symmetrical eight-sided outline, and returns more light than the square, not less.

Try it yourself: See the fire in the 3D Gemstone Simulator

Loses more light when tipped

Tilt 86 against 92 for the T73 Round Brilliant in diamond: 6 points lower

At 20° it keeps 86 of its face-up light, against 92 for the T73, so the square darkens a little more as it moves.

Square Cut in diamond · Tilt 86

Square cut in diamond tilted 0 degrees: Light Return map, 7% of the face leaking0° · 7% leak
Square cut in diamond tilted 10 degrees: Light Return map, 11% of the face leaking10° · 11% leak
Square cut in diamond tilted 20 degrees: Light Return map, 16% of the face leaking20° · 16% leak
Square cut in diamond tilted 30 degrees: Light Return map, 22% of the face leaking30° · 22% leak

T73 Round Brilliant in diamond · Tilt 92

T73 round brilliant in diamond tilted 0 degrees: Light Return map, 4% of the face leaking0° · 4% leak
T73 round brilliant in diamond tilted 10 degrees: Light Return map, 2% of the face leaking10° · 2% leak
T73 round brilliant in diamond tilted 20 degrees: Light Return map, 9% of the face leaking20° · 9% leak
T73 round brilliant in diamond tilted 30 degrees: Light Return map, 14% of the face leaking30° · 14% leak
Tilt is how much of its own face-up light a stone keeps when tilted. Each frame is the Light Return map with the stone tilted away from you by the angle shown; gray is leakage. The share under each frame is that picture's own.

What helps: Close to a square, DG-Octagonal Kite Diamond holds 89 at 20°. For the steadiest light with no loss of brilliance, choose a round such as DG-Rafaello Diamond. It keeps 97, the most of any round we measure in diamond within three points of the T73's brilliance.

Try it yourself: Compare the Tilt spoke in the Cut Performance Wheel

Who a square cut diamond suits

Choose the square brilliant when the outline must be square and light still matters: no square cut we measure in diamond does better.

If you can move away from a strict square, choose DG-Octagonal Kite Diamond. It keeps a symmetrical outline with more light, more fire and a steadier hold when tipped. But it faces up smaller per carat. For a step-cut look, choose the Asscher Cut Diamond, at a large cost in light.

Square Cut Diamond: questions

Is a square cut diamond as brilliant as a round?

No: Brilliance 85 against 93 for the T73, with 10% leakage.

Square or cushion cut diamond?

The square returns more light, 85 against 80. The cushion sparkles more, 85 against 78, and holds its light better when tipped.

Square or princess cut diamond?

The square, by a wide margin in our census: Brilliance 85 against 57 for the princess, and 10% leakage against 18%.

What does a 6.5 mm square cut diamond weigh?

1.14 ct in our model, more than a T73 of that width.

Get the Square Cut files

6 formatsMillimetersWatertight

Square Cut 3D files

The Square Cut as exact geometry: 69 planar facets, real-world scale, ready for CAD, rendering, printing and casting.

  • STEPExact faceted solid for CAD
  • 3DMRhino, closed mesh on its own layer
  • STLWatertight mesh for printing and casting
  • OBJMesh for modeling and rendering
  • FBXBlender, 3ds Max, Maya, Cinema 4D, Unity, Unreal
  • GLBWeb, AR and quick previews
GemCad64 index

Square Cut cutting files

The Square Cut as a faceting design: 57 + 12 girdles = 69 facets, 64 index, 4-fold mirror-image symmetry, ready for the machine.

  • .ascGemCad design file, 64 index gear
  • .csvTier table: angles, indices and cutting order
  • DiagramPrintable faceting diagram

Not sure the files open in your software? Get the cube free: the same six formats, for your email address, used only to send them (privacy).

Questions before you buy? Email us.
